| Monitor Display Spec |
Display size |
47cm / 18.5" Diagonal White LED-Backlight |
| Brightness(Typical) |
200cd/m2 |
| Contrast(Typical) |
600:1 40,000,000:1(active contrast) |
| Pixel Pitch |
0.3(H) x 0.3(V) mm |
| Resolution (H x V) |
1366 x 768 |
| Aspect Ratio |
16:9 |
| Response Time(Typical) |
5ms |
| View Angles LR,UD(CR>10) |
H/V 90°/65° |
| Panel Surface |
AG |
| Display Colors |
16.7M Colors |
| PC Input Range |
Horizontal Freq. |
30 to 61kHz |
| Vertical Freq. |
56 to 75Hz |
| Max. display frequency (Resolution H*V/Fv) |
1366 x 768 /60Hz |
| Interface |
Input 1 |
D-Sub x 1 |
| Output Terminal |
Earphone |
NA |
| Speaker(Typical, Amplifier output) |
NA |
| Power |
Consumption(Typical) |
On: 11W; Stand-by: 0,3W; Off: 0,2W |
| AC Power Range |
AC 100-240, 50-60Hz |
| Power Mode Indicator Light |
Power on : Green Power Saving: Amber |
| Operating Condition |
Temperature |
5 ~ 35℃ |
| Humidity |
20% ~ 85%, non-condensing |
| Physical |
Dimension (W*D*H) |
444.2*185*329.5 mm |
| Packing Dimension (W*D*H) |
492*117*377mm |
| Net Weight |
2.56KG |
| Gross Weight |
3.35KG |
| Bezel Type |
Glossy |
| Tilt |
-3∘~ 17∘ |
| Kensington Lock |
Yes |
| VESA Mounting |
75 x 75 mm |
| Controls |
Front Control |
Menu, Bri (+), (-) Input/Enter, Power |
| On Screen Display |
HSD OSD format 12 language : EN,TC,DE,FR,ES,IT,PT,NL,SC,JS,KR,Russian |
| Color |
WARM,NATURE,COOL, User Mode |
| Preset Mode |
PC, Movie, Game, ECO Modes |
| Accessory |
Power Cable |
Yes(1.5M) |
| VGA Cable |
Yes(1.5M) |
| User Manual(CD) |
Yes, HSD format |
| Quick Start Guide(Paper) |
Yes, HSD format |
| Certification |
CE, CB,PEA6.0 |
