| LCD Panel |
Display size |
68,6cm / 27″ Diagonal LED Monitor |
| Brightness(Typical) |
300cd/m2 (Typical) |
| Contrast(Typical) |
1000:1 (Typical)
80,000,000:1 (Active Contrast ) |
| Pixel Pitch |
0.311(H) x 0.311(V) mm |
| Resolution (H x V) |
1920 x 1080 |
| Aspect Ratio |
16:9 |
| Response Time(Typical) |
5ms |
| View Angles LR,UD(CR>5) |
H/V 178°/178° |
| Panel Surface |
Anti-glare |
| Display Colors |
16.7M colors |
| PC Input Range |
Horizontal Freq. |
30 to 83KHz |
| Vertical Freq. |
56 to 75Hz |
Max. display frequency
(Resolution H*V/Fv) |
1920 x 1080 /60 Hz |
| Interface |
Input 1 |
D-Sub x1 |
| Input 2 |
PC Audio x1 |
| Input 3 |
DVI-D (HDCP) x1 |
| Input 4 |
HDMI x 1 |
Output
Terminal |
Earphone |
NA |
| Speaker(Typical) |
2W x 2 |
| Power |
Consumption(Typical) |
On: 40 W
Standby<=0.5W, Off<=0.5W |
| AC Power Range |
AC 100~240V, 50~60Hz |
Power Mode
Indicator Light |
Power on : Green
Power Saving: Amber |
Operating
Condition |
Temperature |
5℃ ~ 35℃ |
| Humidity |
20% ~ 85%, non-condensing |
| Physical |
Dimension
(W*D*H) |
646.6*220*448mm |
Packing Dimension
(W*D*H) |
710*116*520mm |
| Net Weight |
5.2kg |
| Gross Weight |
6.6kg |
| Bezel Type |
Matt |
| Tilt |
-5∘~ 15∘ |
| High Adjustable Arm |
NA |
| Swivel |
NA |
| Pivot |
NA |
| Kensington Lock |
Yes |
| VESA Mounting |
100 x 100mm |
| Controls |
Front Control |
Menu, Bri (-), Vol(+) Input/Enter, Power |
| On Screen Display |
HSD OSD format, 12 language : EN,TC,DE,FR,ES,IT,PT,NL,SC,JS,KR,Russian |
| Color |
WARM,NATURE,COOL, User Mode |
| Preset Mode |
PC, Movie, Game, ECO Modes |
| Accessory |
Power Cable |
Yes (1.5M) |
| VGA Cable |
Yes (1.5M) |
| Audio Cable |
Yes (1.5M) |
| DVI Cable |
Optional (1.5M) |
| HDMI-DVI Cable |
Optional (1.5M) |
| HDMI-HDMI Cable |
Optional (1.5M) |
| User Manual(CD) |
Yes, HSD format |
| Quick Start Guide(Paper) |
Yes, HSD format |
| Certification |
FCC, UL/CUL , CE, CB, 3C, China Energy Level 1, EnergyStar 6.x,TCO6.0,GS |
