| Monitor Display Spec |
Display size |
60cm / 23.6″ Diagonal White LED-Backlight |
| Brightness(Typical) |
250cd/m2 |
| Contrast(Typical) |
1,000:1
40,000,000:1(active contrast) |
| Pixel Pitch |
0.2715(H) x 0.2715(V) mm |
| Resolution (H x V) |
1920 x 1080 |
| Aspect Ratio |
16:9 |
| Response Time(Typical) |
5ms |
| View Angles LR,UD(CR>10) |
H/V 170°/160° |
| Panel Surface |
AG |
| Display Colors |
16.7M Colors |
| PC Input Range |
Horizontal Freq. |
24 to 83KHz |
| Vertical Freq. |
55 to 75Hz |
Max. display frequency
(Resolution H*V/Fv) |
1920 x 1080 / 60 Hz |
| Interface |
Input 1 |
D-Sub x 1 |
| Input 2 |
DVI-D (w HDCP) x 1 |
| Input 3 |
PC Audio x 1 |
| Input 4 |
NA |
Output
Terminal |
Earphone |
NA |
| Speaker(Typical, Amplifier output) |
1.5W x 2 |
| Power |
Consumption(Typical) |
On: 14W
Standby<=0.39W, Off<=0.29W |
| AC Power Range |
AC 100-240, 50-65Hz |
Power Mode
Indicator Light |
Power on : Green
Power Saving: Amber |
Operating
Condition |
Temperature |
5 ~ 35℃ |
| Humidity |
20% ~ 85%, non-condensing |
| Physical |
Dimension
(W*D*H) |
561*220*399mm |
Packing Dimension
(W*D*H) |
614*109*465mm |
| Net Weight |
4.5kg |
| Gross Weight |
5.4kg |
| Bezel Type |
Glossy |
| Tilt |
-5∘~ 15∘ |
| High Adjustable Arm |
NA |
| Swivel |
NA |
| Pivot |
NA |
| Kensington Lock |
Yes |
| VESA Mounting |
100 x 100 mm |
| Controls |
Front Control |
Menu, Bri (+), Vol(-) Input/Enter, Power |
| On Screen Display |
HSD OSD format 12 language : EN,TC,DE,FR,ES,IT,PT,NL,SC,JS,KR,Russian |
| Color |
WARM,NATURE,COOL, User Mode |
| Preset Mode |
PC, Movie, Game, ECO Modes |
| Loading |
40′ HQ |
US 1680 |
| 40′ Standard |
US 1344/EU 1470 |
| 20′ ‘Standard |
US 640/EU 700 |
| Accessory |
Power Cable(1.5m) |
Yes |
| VGA Cable(1.5m) |
Yes |
| Audio Cable(1.5m) |
Yes |
| DVI Cable(1.5m) |
Optional |
| HDMI-DVI Cable(1.5m) |
NA |
| HDMI-HDMI Cable(1.5m) |
NA |
| YPbPr Cable |
NA |
| User Manual(CD) |
Yes, HSD format |
| Quick Start Guide(Paper) |
Yes, HSD format |
| Color Plan |
Black glossy: front bezel, arm, base
Black texture: back cover |
| Carton Box |
Brown carton, HSD format |
| Green Product (Jan. 2009) |
Yes |
| Windows 7 |
Yes |
| HDMI Logo |
NA |
| Others |
PC99 function (Must) |
| Certification |
FCC, UL/CUL, CE, CB, GOST, 3C, China energy level 1, BSMI, EnergyStar 5.0 |
